0412-1.25-E-14-O-A Siko Digital Position Indicators Rectangular

About 0412-1.25-E-14-O-A Siko Digital Position Indicators Rectangular

The code 0412-1.25-E-14-O-A (often written similarly to your 0412-1.25-E-14-0-A) is a model designation for a mechanical/digital shaft position indicator used on woodworking, packaging, and industrial machinery. The code breaks down as follows:

Code Part	Meaning
0412	Mounting position/type 04, position 12
1.25	Axial pitch of 1.25 mm per revolution
E	Counter increases in the anticlockwise (CCW) direction
14	Hollow shaft bore diameter 14 mm
O	Orange housing/color
A	Standard version (without special options)

This is typically a 4-digit mechanical position indicator/counter mounted directly on an adjustment shaft to show position or travel. It is commonly used for machine settings where repeatable positioning is required.

Reliable Performance and Easy Implementation

Designed for accurate position and rotation tracking, the Siko 0412-1.25-E-14-O-A ensures streamlined machine operation. With an intuitive LCD display and robust housing, it provides reliable feedback even in harsh factory settings. The simple rotary shaft interface and selectable counting make it adaptable to diverse machinery setups, boosting process efficiency.


Efficient, Maintenance-Free Operation

Thanks to its energy-efficient battery power, the indicator delivers instantaneous response and high sensitivity while maintaining up to 5 years of operation per battery. The sealed IP65-rated enclosure requires minimal maintenance and stands up to dust and water, supporting continuous use and minimizing downtime for industrial users.
