R 58 Mark Sensor

ઉત્પાદન વર્ણન

General Description of the R 58 Mark Sensor:

Here™s a typical overview based on industry standards (note: specifics may vary slightly depending on the manufacturer):

1. Purpose:

• Detects registration marks or color contrasts on packaging materials.

• Ensures proper alignment and timing in cutting, labeling, or filling processes.

2. Key Features:

• High contrast sensitivity “ Able to distinguish between slight differences in color or grayscale.

• Fast response time “ Essential for high-speed production lines.

• Adjustable sensitivity and threshold “ Manual or auto-teach functions to optimize detection accuracy.

• LED or Laser light source “ Provides consistent, sharp detection.

• Compact housing “ Fits into tight spaces in machinery.

3. Common Specifications:

• Sensing distance: Typically a few millimeters (e.g., 10“15 mm).

• Light source: Red LED (commonly), sometimes green or blue for better color differentiation.

• Response time: <50 microseconds in many models.

• Output types: NPN/PNP transistor output, often with normally open/closed options.

• Power supply: 10“30 VDC.

4. Applications:

• Label positioning in labeling machines.

• Cutting position control in packaging lines.

• Print mark detection in printing machines.

• Web guiding in roll-fed systems.

5. Common Manufacturers:

• Banner Engineering “ Often uses the "R58" naming for high-performance registration mark sensors.

• Other companies might use similar nomenclature but refer to slightly different models.
