Label Gap Sensor GAP-VE04B04M8

Name: Label Gap Sensor GAP-VE04B04M8
Brand: GENESIS TECHNOMATION INDIA PRIVATE LIMITED
Price: 3100.0 INR
Availability: InStock

Price 3100.00 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

Label Gap Sensor GAP-VE04B04M8 Specification

Ingress Protection
IP67

Application
Label counting, edge sensing, gap detection

Signal Type
Digital (NPN/PNP)

Housing Material
Plastic

Cable Length
2 m

Sensitivity
Adjustable

IP Rating
IP67

Wireless
No

Interface
Wired, open ended

Power Consumption
<2 W

Response Time
<1 ms

Measurement Range
Label gap width: 2-10 mm

Sensor Type
Slot Sensor / Fork Sensor

Spectral Range
Infrared

Mounting Type
Through hole

Operating Temperature
-10C to +60C

Features
High-speed response, LED indicators, robust design

Product Type
Label Gap Sensor

Material
Plastic

Input
10-30V DC

Output
NPN/PNP

Function
Detection of label gaps

Usage
Used in labeling machines for detecting the gap between labels

Accuracy
High precision

Resolution
0.05 mm

Voltage
10-30V DC

Weight
Approx. 80 g

Compatible Label Materials
Paper, foil, transparent plastic

Protection Features
Reverse polarity and short circuit protection

Adjustment Method
Manual (+ / -) buttons

Fork Width
4 mm

Fork Depth
40 mm

Indicator
LED Status Indicators

Storage Temperature
-20C to +70C

Connection Type
3-wire configuration

Label Gap Sensor GAP-VE04B04M8 Trade Information

Minimum Order Quantity
100 Pieces

Delivery Time
1 Hours

Label Gap Sensor GAP-VE04B04M8 About

The GAP-VE04B04M8 is a fork-type label gap sensor used in automatic labeling machines to detect the gap between labels on a backing liner. It ensures accurate label positioning during high-speed labeling operations.

Typical Specifications

Model: GAP-VE04B04M8
Type: Fork Label Gap Sensor
Sensing Method: Optical (Infrared)
Fork Gap: 4 mm
Power Supply: 1030 VDC (typical)
Output: PNP or NPN (depends on model variant)
Connector: M8, 4-pin
Protection Rating: IP67
Application: Detection of opaque and semi-transparent label gaps on label dispensing machines.

Exceptional Precision and Flexibility

The GAP-VE04B04M8 sensor is tailored for high-precision gap detection in label processing with an outstanding 0.05 mm resolution. With adjustable sensitivity and compatibility with various label materials, this sensor ensures reliability for any labeling machine application. The manual (+/-) control allows instant adjustment to different setups, optimizing detection accuracy and efficiency.

Robust Design for Industrial Environments

Protected by an IP67-rated plastic housing, the GAP-VE04B04M8 is built to withstand harsh industrial conditions. It is equipped with reverse polarity and short-circuit protection, enabling stable operation even in challenging environments. Its high-speed processing and durable construction make it ideal for continuous, demanding use.

FAQ's of Label Gap Sensor GAP-VE04B04M8:

Q: How do I adjust the sensitivity of the GAP-VE04B04M8 label gap sensor?

A: You can manually adjust the sensor's sensitivity using the (+) and (-) buttons on the device. This feature allows you to fine-tune the sensor for different label materials and gap widths, ensuring optimal detection accuracy.

Q: What types of label materials is this gap sensor compatible with?

A: The GAP-VE04B04M8 is compatible with paper, foil, as well as transparent plastic labels, making it suitable for a wide variety of labeling applications.

Q: Where is this sensor typically installed, and what mounting method does it use?

A: This sensor is usually mounted on labeling machines using the through-hole installation method. Its compact fork design (4 mm width, 40 mm depth) enables easy integration in various labeling setups.

Q: What are the main protective features of this sensor and how do they benefit operations?

A: The sensor offers reverse polarity and short-circuit protection, safeguarding against wiring errors and unexpected faults, which ensures continuous, safe operation and prolongs the device's lifespan.

Q: When is it ideal to use the GAP-VE04B04M8 sensor in the labeling process?

A: This sensor is best used during label application, counting, and edge sensing, particularly when high precision and reliability are required to detect narrow gaps between labels.

Q: What is the response time of this sensor, and why is it important for labeling machines?

A: The sensor responds in under 1 ms, which is crucial for high-speed labeling operations. This rapid response ensures accurate detection without slowing down production.

Q: What benefits do the LED status indicators provide to users?

A: The integrated LED indicators display the operational and detection status clearly, allowing for swift troubleshooting and confirmation of sensor activity during operation.
