M30 GX Inductive Proximity Sensor

Name: M30 GX Inductive Proximity Sensor
Brand: GENESIS TECHNOMATION INDIA PRIVATE LIMITED
Price: 498.0 INR
Availability: InStock

Price 498.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

M30 GX Inductive Proximity Sensor Specification

Resistance
200 mA

Output
PNP NO (Normally Open)

Theory
Other

Type
Inductive Proximity Sensor

Accuracy
5% of sensing distance

Operating Voltage
10V to 30V DC

Output Voltage
10V to 30V DC

Compensated Temperature
-10C to +60C

Storage Temperature
-40C to +85C

Operating Temperature
-25C to +70C

Enclosure Material
Nickel Plated Brass

Sensing Distance
10 mm (typical)

Indicator
Red LED

Protection Degree
IP67

Shell Diameter
M30

Ripple
10%

Connection Type
2 Meter PVC Cable

Switching Frequency
200 Hz

Hysteresis
10% of sensing distance

Mounting Type
Flush/Shielded

M30 GX Inductive Proximity Sensor Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1 Days

About M30 GX Inductive Proximity Sensor

An M30 GX sensor is a threaded (30 mm diameter) inductive proximity sensor with a built-in amplifier and DC 3-wire operation. It detects metallic targets without physical contact using an electromagnetic field.Key Features

Type: Inductive proximity sensor (metal detection only)
Size: M30 threaded cylindrical body
Construction: Nickel-plated brass housing (rugged industrial design)
Mounting: Shielded (flush mounting possible)
Sensing Distance:
- Standard: ~810 mm
- Long range: up to ~15 mm
Supply Voltage: 1030 V DC
Output Types:
- PNP / NPN
- Normally Open (NO) or Normally Closed (NC)
Connection: Cable or M12 connector
Protection Rating: IP67 / IP69K (dustproof & waterproof)
Temperature Range: approx. 25C to +70C (up to 40C to +85C in some models)

Working Principle

The sensor generates an electromagnetic field at its sensing face.
When a metal object enters this field, eddy currents are induced.
This causes a change in the sensors internal oscillator.
The sensor then switches its output (ON/OFF signal).

Special Features (GX Series)

Built-in amplifier (no external amplifier needed)
360 visible LED indicator for easy status checking
Some models support IO-Link communication for smart factory integration
High durability for harsh environments (oil, dust, vibration)

Applications

Conveyor systems (object detection)
CNC and machine tools
Packaging and automation lines
Position and limit sensing
Metal part counting

Summary

An M30 GX inductive proximity sensor is a robust, industrial-grade metal detection sensor with a large sensing head (M30), suitable for heavy-duty automation applications where reliability, durability, and non-contact sensing are required.

High-Precision Metal Detection

The M30 GX inductive proximity sensor utilizes electromagnetic fields to detect metal objects quickly and accurately. With a 10 mm sensing distance and a tight hysteresis of 10%, it ensures consistent results, making it well-suited for industrial automation, assembly lines, and machinery safety applications.

Durable and Reliable Construction

Featuring an enclosure crafted from nickel-plated brass, the sensor withstands harsh industrial environments. Its IP67 protection degree resists dust and water ingress, while the robust build and 2-meter PVC cable allow for both reliable operation and flexible installation in challenging settings.

Flexible Installation and Operation

This sensor is compatible with flush (shielded) mounting, making it adaptable for integration into a variety of equipment. The PNP NO (Normally Open) output allows easy connection to control systems, and real-time feedback is provided via an integrated red LED indicator.

FAQ's of M30 GX Inductive Proximity Sensor:

Q: How do I install the M30 GX Inductive Proximity Sensor for optimal performance?

A: For optimal performance, mount the sensor using the flush (shielded) method in metal surfaces, ensuring the sensing face is aligned with the target approach. Use the provided 2-meter PVC cable for secure electrical connections, and follow the operating voltage range of 10V to 30V DC.

Q: What types of objects can the M30 GX sensor detect?

A: The sensor is specifically designed to detect metallic objects, including iron, steel, and other conductive metals. Non-metallic materials such as plastic or wood will not be detected due to its inductive sensing principle.

Q: When should I use an IP67-rated sensor like the M30 GX?

A: Use an IP67-rated sensor when the application environment involves exposure to dust, moisture, or water splashes. The IP67 rating means the sensor is protected against total dust ingress and can withstand temporary immersion in water, making it suitable for demanding industrial settings.

Q: Where is the ideal place to install the M30 GX Inductive Proximity Sensor?

A: The sensor is ideal for installation in industrial automation setups, production lines, or machinery where non-contact, reliable metal detection is essential. It can be mounted on machine frames, conveyor systems, or in enclosures exposed to environmental stressors.

Q: What is the process for connecting the sensor to my control system?

A: Connect the sensor's output (PNP, Normally Open) to your control circuit's input, ensuring the supply voltage is between 10V and 30V DC. The 2-meter PVC cable facilitates a straightforward setup. Refer to wiring diagrams and proper electrical practices for effective integration.

Q: How can I verify if the sensor is operating correctly?

A: Observe the red LED indicator on the sensor body. It lights up when a metal object is within the 10 mm sensing distance, confirming successful detection and operation of the sensor.

Q: What key benefits does this sensor offer for industrial users?

A: The M30 GX offers accurate metal detection, high switching frequency (200 Hz), robust IP67 durability, reliable output (PNP NO), and flexible mounting. These features combine to enhance process reliability, reduce downtime, and streamline automation in industrial environments.
