QS18VN6D Diffuse sensor NPN

Name: QS18VN6D Diffuse sensor NPN
Brand: GENESIS TECHNOMATION INDIA PRIVATE LIMITED
Price: 2000 INR
Availability: InStock

Price 2000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

QS18VN6D Diffuse sensor NPN Specification

Resistance
Load current: 150 mA max.

Output
NPN

Theory
Photoelectric sensor

Type
Diffuse sensor

Accuracy
10% of sensing distance

Operating Voltage
10 to 30 VDC

Output Voltage
30V DC max.

Storage Temperature
-40C to +70C

Operating Temperature
-40C to +70C

Enclosure Rating
IP67

Light Source
Red LED

Dimensions
18 mm x 50 mm x 34 mm

Material
ABS plastic housing

Sensing Distance
200 mm

Response Time
1 ms

Connection Type
Cable, 2 m

About QS18VN6D Diffuse sensor NPN

Key Specifications

Sensing Mode: Mouser Electronics+11DigiKey+11DigiKey+11turck.deNewark Electronics+9store.gilsoneng.com+9DigiKey+9Banner Engineering+11Mouser Electronics+11Farnell+11turck.de+12DigiKey+12DigiKey+12RS Components+1store.gilsoneng.com+1Farnell+4All Data Sheet+4Banner Engineering+4

Purchasing Options in India

Tradeindia

RS Components+5Mouser Electronics+5DigiKey+5

Alternative Models

Depending on your specific application requirements, you might consider the following variants:

Banner Engineering QS18VN6DQ8 Photoelectric Sensor: Banner Engineering QS18VP6D Photoelectric Sensor:

Dependable Object Sensing with Precision

The QS18VN6D diffuse sensor excels in fast, accurate object detection. Leveraging photoelectric technology with a Red LED, it reliably senses up to 200 mm with 10% tolerance. Its robust design withstands challenging industrial conditions and delivers consistently precise results in automated environments.

Built to Endure Harsh Industrial Environments

Encased in IP67-rated ABS plastic housing, the QS18VN6D resists dust, water, and physical impacts. Operating from -40C to +70C, it performs flawlessly in varying climates and intense production settings, ensuring minimal maintenance and longevity for users in Indias demanding industries.

Seamless Integration and Quick Response

Featuring a user-friendly 2-meter cable connection, the QS18VN6D integrates easily into new or existing setups. Its rapid 1 ms response time and high load current capacity make it ideal for real-time monitoring and swift operational feedback in manufacturing processes.

FAQs of QS18VN6D Diffuse sensor NPN:

Q: How do I install the QS18VN6D diffuse sensor in my system?

A: To install the QS18VN6D, mount the ABS plastic housing in the desired position using the provided dimensions (18 x 50 x 34 mm). Connect the 2 m cable to your control circuit, ensuring you operate within the 1030 VDC voltage range and observe correct NPN wiring.

Q: What types of objects can the QS18VN6D detect using its photoelectric sensing theory?

A: The QS18VN6D effectively detects a variety of opaque, reflective, or colored objects within its 200 mm sensing range, leveraging its diffuse, photoelectric sensing capabilities and Red LED light source. However, extremely shiny or transparent surfaces may require careful alignment.

Q: When should I consider using a diffuse sensor like the QS18VN6D over other sensor types?

A: Choose the QS18VN6D for applications needing contactless detection of objects where installation space is compact and rapid response (1 ms) is critical. It is particularly beneficial in automated assembly, packaging lines, and object counting tasks.

Q: Where can the QS18VN6D be used given its enclosure rating and temperature range?

A: Thanks to its IP67 enclosure and wide operating temperature range (-40C to +70C), the QS18VN6D is suitable for indoor and outdoor industrial environments, including manufacturing floors, warehouses, and wet or dusty locations.

Q: What is the process for wiring the NPN output on this sensor?

A: Connect the sensors supply wires to your 1030 VDC power source. The NPN (open collector) output switches the ground connection when an object is detected, allowing readout by most PLC or control inputs. Ensure the total load doesnt exceed 150 mA and the output voltage remains below 30V DC.

Q: How does using the QS18VN6D benefit my automation process?

A: Using the QS18VN6D enhances process efficiency by delivering quick and accurate object detection without physical contact, minimizing downtime, and ensuring reliable production flow. Its durability and easy integration make it a low-maintenance and cost-effective solution for industrial automation.
