QS18VP6D diffuse PNP sensor

Name: QS18VP6D diffuse PNP sensor
Brand: GENESIS TECHNOMATION INDIA PRIVATE LIMITED
Price: 2000 INR
Availability: InStock

Price 2000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

QS18VP6D diffuse PNP sensor Specification

Product Type
QS18VP6D diffuse PNP sensor

Color
Black

Usage
Industrial

Material
ABS

Voltage
220-440 Volt (v)

Output
PNP

Theory
Other

Type
Diffuse sensor

Operating Voltage
10-30 VDC

Output Voltage
10-30 VDC

Storage Temperature
-40°C to +70°C

Operating Temperature
-20°C to +55°C

Sensing Range
0-400 mm

Light Source
Red LED

Response Time
<1 ms

Housing Dimensions
Rectangular, 18 mm

IP Rating
IP67

Connection Type
M12 connector or 2 m cable

About QS18VP6D diffuse PNP sensor

Diffuse Mode: The sensor emits a beam of light (usually visible red) and detects the reflection off a target. The sensor and the target are in the same area ï no separate reflector is required.
Object detection is based on how much light is reflected back from the object.

Advanced Detection Technology

Built with diffuse sensing technology, the QS18VP6D offers accurate target detection for a variety of industrial applications. Its red LED light source ensures stable performance, even in complex or challenging environments, enabling reliable operation day after day.

Robust Construction and Versatility

Encased in a compact 18 mm ABS housing, this sensor stands up to rough conditions, thanks to its IP67-rated enclosure. The choice of M12 connector or 2 m cable gives flexibility for different installation scenarios on factory floors or automated lines.

Optimized for Fast-Paced Industries

With a response time of less than 1 ms and a wide operating temperature range, the QS18VP6D is well-suited to the rapid demands of modern industry. Its PNP output simplifies integration with most industrial controllers, promoting efficient workflows and dependable automation.

FAQ's of QS18VP6D diffuse PNP sensor:

Q: How is the QS18VP6D diffuse PNP sensor typically installed in industrial settings?

A: The QS18VP6D can be installed using its rectangular 18 mm ABS housing and mounted to machinery or fixed positions in production lines. Users can choose between an M12 connector or a pre-attached 2-meter cable for easy integration into their control panels or PLC systems.

Q: What types of surfaces or objects can this sensor detect?

A: As a diffuse sensor with a red LED light source, the QS18VP6D is capable of detecting most non-transparent objects within its 0-400 mm sensing range. It works efficiently on surfaces that reflect light, making it suitable for a wide variety of industrial materials and products.

Q: When should I select a diffuse sensor like the QS18VP6D over other sensor types?

A: A diffuse sensor is ideal when you need to detect the presence or absence of objects without additional reflectors or separate receivers. Choose the QS18VP6D for straightforward detection tasks where objects pass within 400 mm of the sensor in applications such as packaging, sorting, or assembly.

Q: Where can the sensor be safely operated and stored?

A: The sensor can be safely operated in temperatures ranging from -20C to +55C and stored between -40C and +70C. Its IP67 rating means it withstands dust and water exposure, making it a reliable choice for both clean and demanding industrial locations.

Q: What is the process for connecting the QS18VP6D sensor to industrial equipment?

A: Connection is straightforward-simply use either the M12 connector or the attached 2 m cable to connect to your control device. The sensor operates on 10-30 VDC, and its PNP output allows for direct integration into compatible automation systems.

Q: How does using the QS18VP6D benefit industrial operations?

A: Using this sensor enhances automation efficiency, thanks to its quick response time and reliable sensing capabilities. Its sturdy build and flexible installation options minimize downtime and maintenance, supporting uninterrupted workflow and consistent production quality.
